S4052B SWIVEL 300 SERIES CASTR
100mm Cast Iron Wheel 200kg Capacity Castor (S4052B)
The S4052B by Richmond Wheel and Castor Co. is a swivel frame castor and features a cast iron wheel. This swivel castor is in our 300 series plate range and has a top load capacity of 200kg. The S4052B wheel is fitted with ball bearings and is baseplate mount. The swivel frame of this castor allows the castor to swivel 360°. The overall cast iron wheel diameter is 100mm, the wheel width is 38mm and can be ordered separately (Ci400). For the same castor without a brake, see S4052.
| Product Code | S4052B |
|---|---|
| Wheel Diameter (mm) | 100 |
| Frame Type | Swivel with Brake |
| Wheel Width (mm) | 38 |
| Wheel Type | Cast Iron |
| Wheel Code | Ci400 |
| Wheel Bearing Type | Ball Bearing |
| Castor Height (mm) | 130 |
| Swivel Radius (mm) | 125 |
| Maximum Load Capacity (kg) | 200 |
| Recommended Load Capacity (kg) | 150 |
